Tectum Roof Deck Specifications

Key features sound absorption nrc up to 0 80 r value up to 6 spans up to 6 feet 50 pound design load diaphragm shear up to 542 dsn lf nailable surface low slope applications.

Tectum roof deck specifications. Tectum ns roof deck panels. Acoustics insulation and nailable surface in one panel. Spans up to 6 feet. Ideal for hurricane prone areas that require miami dade noa approval these three in one composite roof deck panels provide acoustics insulation and a nailable surface that accepts a wide variety of roofing materials.

Roof deck wall ceiling panels when noise control durability matter. The inclusion of another manufacturers products of specifications in our literature does not indicate an endorsement or guarantee. R value up to 6. Tectum tiles must have 1 2 minimum bearing.

East lawrence recreation center lawrence ks tectum i roof deck key selection attributes. Tectum e tectum e n. Tectum iiiw roof deck. Ideal for hurricane prone areas that require miami dade noa approval these three in one composite roof deck panels provide acoustics insulation and a nailable surface that accepts a wide variety of roofing materials.

Tectum ns is typically used in sloped applications where minimal insulation is required. This bulletin also addresses foam adhesive attachment of insulation to tectum i roof decks. See technical bulletin t 38 for information on fastener attachment of insulation to tectum i roof decks. Tectum i roof deck panels consist of standard tectum panels in either plank or tile configuration.

Sound absorption nrc up to 0 80. Specifications for removing and replacing damaged cementitious roof deck panels page 1 of 5 procedures step 1. A plank with t g sides and self support between purlins. B tile with support on sides with bulb or truss tees.

Standard widths diaphragm shear up to 542 dsn lf. Key features sound absorption nrc up to 0 60 r value up to 44 spans up to 8 feet 50 pound design load diaphragm shear up to 786 dsn lf nailable surface low or high slope applications. Tectum iii tectum iiip composite roof deck solution with good sound absorption r values up to 44 and high humidity application performance. Excellent sound absorption available in plank long span plank and tile.

Tectum iiip edge detail is specifically designed for high humidity applications. Composite roof deck solution with good sound absorption r values up to 36 for long span applications up to 12 feet.
